8104116203 ANTUNES RLGP-G 🔥

1–20" W.C. Open Low Auto Reset Gas Pressure Switch (1/4" NPT)

The Antunes RLGP-G Low Gas Pressure Switch is designed for safety and reliability in commercial and industrial gas-fired systems. It automatically shuts down operation when gas pressure drops below a set threshold, then auto-resets when pressure returns to normal.

✅ Key Features

✅ Pressure Range: 1–20" W.C.
✅ Connection Size: 1/4" NPT
✅ Auto Reset: Automatically restores system function when pressure normalizes
✅ Max Surge Pressure: 15 PSIG
✅ Operating Temperature: -40°F to 140°F
✅ Model: RLGP-G (Low Gas Pressure Switch)
✅ Rugged Construction: Built for demanding gas-fired applications
✅ UL Recognized Component

⚠️ Important Note

The RLGP-G model is a low gas pressure switch with auto-reset function. Ensure proper calibration during installation for optimal performance and safety.

🔧 Technical Specifications

🚨 Common Symptoms of Failure

• ❌ Burner fails to ignite or shuts down intermittently

• ⚠️ Unit locks out due to low gas signal

• 💨 Pressure readings fluctuate beyond set range

• 🔌 System fails to auto-reset after low-pressure event

❓ FAQ

Q: What type of pressure does this switch monitor?
✅ It monitors low gas pressure (opens on low).

Q: What happens if the gas pressure drops too low?
✅ The switch opens to interrupt system operation and automatically resets once pressure returns to normal.

Q: What are the electrical ratings?
✅ Rated for 10A @ 125/250 VAC and 1/2A @ 125 VDC.

Q: Is it suitable for outdoor use?
⚠️ The switch must be protected from direct weather exposure; install in a controlled environment when possible.

Q: What’s the maximum surge pressure?
✅ Up to 15 PSIG.

🛒 Shopping Tips

• 🧰 Verify the pressure range (1–20" W.C.) matches your system’s requirements.

• 🔄 Replace if you experience frequent lockouts or low flame issues.

• ⚙️ Always install using properly calibrated test equipment.

• 🧾 Genuine Antunes components ensure OEM-level reliability and safety.
