CARLIN EZ-1 OIL BURNER WITH 40200 INTERRUPTED DUTY CONTROL, 41000 IGNITOR, CAD CELL, 1 STAGE PUMP
LESS BLAST TUBE AND FLANGE
0.5 to 1.65 GPH
Fuels
U.S. - No. 1 or No. 2 Fuel Oil
Canada - No. 1 Oil or No. 2 Furnace Oil
Ignition
Carlin Model 41000 solid state electronic ignition
Ignition Voltage: 14,000 volts
Electrical
Power: 120 vac, 60Hz, 1-Phase
Current: Approximately 5.8 Amps
Limit Circuit Input: 120 vac, 60 Hz
Motor (PSC): 1/6 HP, 3450 RPM
Motor Frame: 48-Frame, "M" Flange
Oil Valve Power: 120 vac, 60 Hz
Nozzle Line Heater: 120 vac, 60 Hz
Alarm Contacts (Isolated): 24 VAC/VDC, 2 Amps
