REPLACES M744S1005 120V 50/60HZ 2.9VA 150LB-IN 90

Manufacturer: Honeywell

- 120V - 50/60Hz - Torque: 150 lb-in - Wiring Screw Terminals - Fail Safe Mode Non-spring Return - Control Signal 4 to 20mA - Timing 30 to 60 Seconds - Mount Foot - 2 Motor Shafts Features • Integral spring return returns motor to normal position when power is interrupted. • Integral junction box provides NEMA 3 weather protection. • Motor and circuitry operate from 24 Vac. Models available with factory installed transformer, or a field added internal transformer. • Quick-connect terminals are standard—screw terminal adapter is available. • Adapter bracket for matching shaft height of older motors is available. • Most motors have field adjustable stroke (90° to 160°). • Die-cast aluminum housing. • Integral auxiliary switches are available factory mounted, or can be field added. • Nominal timing standard of 30 seconds (90° stroke), and 60 seconds (160° stroke). Other timings available. • Spring return motors can operate valve linkages from power end or auxiliary end shafts for normally closed or normally open valve applications. • All models have dual shafts (slotted and tapped on both ends). • All models have auxiliary switch cams. • Fixed torque throughout the entire voltage range. • Motors are designed for either normally open or normally closed valves and dampers. The Series 71, 72 and 76 Modutrol IV Motors are spring return and non-spring return motors used to control dampers and valves. The motors accept a current or voltage signal from an electronic controller to position a damper or valve at any point between open and closed.

SKU: HONEYWELL:M7284A1004

Product Availability: 1

$1,132.55

This product must be purchased in increments of 1

Qty:

i h

- 120V
- 50/60Hz
- Torque: 150 lb-in
- Wiring Screw Terminals
- Fail Safe Mode Non-spring Return
- Control Signal 4 to 20mA
- Timing 30 to 60 Seconds
- Mount Foot
- 2 Motor Shafts

Features
• Integral spring return returns motor to normal position when power is interrupted.
• Integral junction box provides NEMA 3 weather protection.
• Motor and circuitry operate from 24 Vac. Models available with factory installed transformer, or a field
added internal transformer.
• Quick-connect terminals are standard—screw terminal adapter is available.
• Adapter bracket for matching shaft height of older motors is available.
• Most motors have field adjustable stroke (90° to 160°).
• Die-cast aluminum housing.
• Integral auxiliary switches are available factory mounted, or can be field added.
• Nominal timing standard of 30 seconds (90° stroke), and 60 seconds (160° stroke). Other timings available.
• Spring return motors can operate valve linkages from power end or auxiliary end shafts for normally closed
or normally open valve applications.
• All models have dual shafts (slotted and tapped on both ends).
• All models have auxiliary switch cams.
• Fixed torque throughout the entire voltage range.
• Motors are designed for either normally open or normally closed valves and dampers.

The Series 71, 72 and 76 Modutrol IV Motors are spring return and non-spring return motors used to control dampers and valves. The motors accept a current or voltage signal from an electronic controller to position a damper or valve at any point between open and closed.
