RM7823A1016 HONEYWELL PRIMARY FLAME SWITCH 120V 60/50HZ

Manufacturer: Honeywell

RM7823A1016 HONEYWELL PRIMARY FLAME SWITCH 120V 60/50HZ - 120V - 50/60Hz - With Dust Cover - Operating Temp -40 to 140 F Use with R7847, R7848, R7849 and R7886 amplifiers Safety Features Safety features: - Dynamic AMPLI-CHECK - Dynamic self-check logic. - Tamper resistant logic. Features - Can be fitted with any 7800 Series Amplifier to provide relay action from two single pole, double throw (SPDT) relays when flame is present or not present. RM7823A and EC7823 are a flame detector relays only. - Suitable primary control must be used to provide safe-start check, safety lockout, load switching and other functions required in flame safeguard systems. - Three LEDs to indicate power, flame and alarm. - Access for external electrical voltage checks. - Nonvolatile memory. - Shutter drive output. - Compatible with existing Honeywell flame detectors. The Honeywell EC7823/RM7823 is a microprocessor based Flame Detector Relay that can be fitted with any 7800 SERIES amplifier to provide relay action from one relay with 2 single poles, double throw (spdt) circuits when flame is present or not present. The EC7823/RM7823 Relay Module, Q7800 Wiring Subbase and Amplifier are required to complete the system. Options include Keyboard Display Module, Personal Computer Interface, DATA CONTROLBUS MODULE, Remote Display Module, First-Out Expanded Annunciator and COMBUSTION SYSTEM MANAGE Software. Functions provided by the EC7823/RM7823 include flame monitoring, system status indication, system or self-diagnostics and troubleshooting. The EC7823/RM7823 is a flame detector relay only. Suitable primary control must be used to provide safe start check, safety lockout, load switching and other required in flame safeguard systems.

SKU: HONEYWELL:RM7823A1016

Product Availability: Out of stock

$542.45

This product must be purchased in increments of 1

Qty:

i h

RM7823A1016 HONEYWELL PRIMARY FLAME SWITCH 120V 60/50HZ

- 120V
- 50/60Hz
- With Dust Cover
- Operating Temp -40 to 140 F

Use with R7847, R7848, R7849 and R7886 amplifiers

Safety Features
Safety features:
- Dynamic AMPLI-CHECK
- Dynamic self-check logic.
- Tamper resistant logic.

Features
- Can be fitted with any 7800 Series Amplifier to provide relay action from two single pole, double throw (SPDT) relays when flame is present or not present. RM7823A and EC7823 are a flame detector relays only.
- Suitable primary control must be used to provide safe-start check, safety lockout, load switching and other functions required in flame safeguard systems.
- Three LEDs to indicate power, flame and alarm.
- Access for external electrical voltage checks.
- Nonvolatile memory.
- Shutter drive output.
- Compatible with existing Honeywell flame detectors.

The Honeywell EC7823/RM7823 is a microprocessor based Flame Detector Relay that can be fitted with any 7800 SERIES amplifier to provide relay action from one relay with 2 single poles, double throw (spdt) circuits when flame is present or not present. The EC7823/RM7823 Relay Module, Q7800 Wiring Subbase and Amplifier are required to complete the system. Options include Keyboard Display Module, Personal Computer Interface, DATA CONTROLBUS MODULE, Remote Display Module, First-Out Expanded Annunciator and COMBUSTION SYSTEM MANAGE
Software.

Functions provided by the EC7823/RM7823 include flame monitoring, system status indication, system or self-diagnostics and troubleshooting. The EC7823/RM7823 is a flame detector relay only. Suitable primary control must be used to provide safe start check, safety lockout, load switching and other required in flame safeguard systems.

Products specifications

Manufacturer	Honeywell
