120V
50/60Hz
- Includes Integral transformer, enclosure.
- Electrical Ratings Maximum Input-5.0 W
- Temperature Ratings 115 F maximum ambient for 60 Hz. 105 F Max. Ambient for 50 Hz.
- Switching SPST
- Contact Ratings (AFL) At 120 Vac-- 10.2A; 240 Vac-- 5.1A
- Contact Ratings (ALR) At 120 Vac-- 61.2A; 240 Vac-- 30.6A
- Contact Ratings (resistive) At 120 Vac-- 10A; 240 Vac-- 6.0A
- Coil Ratings Current 0.4A
- Coil Ratings Voltage 24 Vac
Features
- Integral transformer provides low voltage power for control circuit.
Provide intermediate switching of a line voltage device from a low voltage controller.
Provide intermediate SPST switching of a line voltage device from a low voltage controller.
